RK060torque transducer

Shaft to Shaft Rotary Torque
Torque Range: 10,000 N·m to 60,000 N·m(7,375 lb·ft to 44,250 lb·ft)
±10,000 N·m (7,375 lb·ft) 口
±20,000 N·m (14,750 lb·ft) 口
±30,000 N·m(22,125 lb·ft) 口
±50,000 N·m(36,875 lb·ft) 口
±60,000 N·m(44,250 lb·ft) 口

24-hour national online service:

025-84363968

consult

Introduction
List
Notice

RK060

Torque Range:10,000N?m to 60,000 N?m (7,375 lb?ft to 44,250 lb?ft

RanKong Series For dynamic torque and speed measurement, RanKong offers the RK060, RK060 Series of high-performance torque meters. All RK060 transducer models employ our unique non-contact differential transformer torque measuring technology. This measuring technology offers many benefits, most notably that no electronic components rotate during operation. Each model has an integrated conditioning electronic module providing a 0 to ±10 VDC torque output and an open collector speed output. RanKong's Torque Transducers are very reliable, providing high overload protection, excellent long-term stability and high noise immunity.
Shaft to Shaft Rotary Torque
Torque Range: 10,000 N·m to 60,000 N·m(7,375 lb·ft to 44,250  lb·ft)
                        ±10,000 N·m (7,375 lb·ft) 口
                        ±20,000 N·m (14,750 lb·ft) 口
                        ±30,000 N·m(22,125 lb·ft) 口
                        ±50,000 N·m(36,875 lb·ft) 口
                        ±60,000 N·m(44,250 lb·ft) 口
Supply Voltage：8 to 30VDC(+24VDC)±15VDC
Output Signal：0 ~ 5V, 1 ~ 5V, 0 ~ 10V , (4 ~ 20mA), 20 ~ 4mA, 5 ~ 0V and other user-specific specifications.
High Speed Applications: up to (6,000 rpm) 10,000 rpm口
                                                20,000 rpm口30,000 rpm口
Work environment：Operating temperature range -20℃~60℃
Overload Capacity: 200%
Accuracy：±0.1%口±0.25%, ±0.5%,口±1.0% (±0.25%)
Linearity：<0.1%
Long Term Stability ：<0.1% FS per year
With a humidity lower than 90%RH
Non-Contact (no slip rings)
No Electronic Components in Rotation
No Electrical Noise
