Torque transducer-RK-064A
Full Scale Range from 1 to 10 N.m and 80 to 3000 N.m
24-hour national online service:
025-84363968- Introduction
- List
- Notice
Reaction torque transducers type RK064ARD are
used for static and quasi-static applications.
By that way a maintenance-free torque
measuring is possible.
The applications are used for adjusting torque
at machine elements, measuring of stirring
devices and checking motors as well as
hydraulic pumps. These models are suitable
for all flange mounting situations.
Excellent cost performance ratio
Accessories (to be ordered separately) :
Connecting , length 3 m
used for static and quasi-static applications.
By that way a maintenance-free torque
measuring is possible.
The applications are used for adjusting torque
at machine elements, measuring of stirring
devices and checking motors as well as
hydraulic pumps. These models are suitable
for all flange mounting situations.
| Rated capacity | ±1 N?m ~ ±3 kN?m |
| Safe overload | 150 %R.C. |
| Ultimate overload | 300 %R.C. |
|
Supply Voltage： Rated output |
8 to 30VDC(+24VDC)±15VDC 0 V ~ ±10 V0 V ~ ±5 V 4-20mA 5-15kHz 485 CAN |
| Accuracy of detected value |
Digital : ±0.5 %R.O., Analog : ±0.25%R.O.±0.1%R.O. (including linearity, hysteresis and repeatablity.) |
Excellent cost performance ratio
Accessories (to be ordered separately) :
Connecting , length 3 m
